| Model | Lifting Capacity (top layer) | Lifting Speed m/min | Motor Output 110V kw x A | Motor Output 220-240V kw x A | Braking Methods For gear | Brake | Lifting Height m | Wire Rope Φ mm×m | Percentage Duty Cycle |
| CHIYEAH KIO-180S | 180 Kg | 15~22 | 1.2 x 12 | 1.2 x 6 | series wound | mechanical ratchet | 29 | 5 x 30 | 25% ED |
| CHIYEAH KIO-240 | 180 Kg | 15~22 | 1.2 x 12 | 1.2 x 6 | series wound | mechanical ratchet | 29 | 5 x 30 | 25% ED |
| CHIYEAH KIO-300AS | 300 Kg | 9~14 | 1.5 x 7 | series wound | mechanical ratchet | 24 | 5 x 25 | 25% ED |
Winches are not to be used for the moving of persons
Each new winch is guaranteed against defects in workmanship and material defects for a period of twelve months from date of purchase
| Model | STANDARD ACCESSORIES | PACKAGE |
| CHIYEAH KIO-180S | – 5 mm x 30 m wire rope and hook K-11 – Pendant control K613 |
– Winch Weight : 19 kg – Gross Weight : 25 kg – Box Dimension : 500 x 250 x360 mm |
| CHIYEAH KIO-240 | – 5 mm x 30 m wire rope and hook K-11 – Pendant control K613 |
– Winch Weight : 19 kg – Gross Weight : 25 kg – Box Dimension : 500 x 250 x360 mm |
| CHIYEAH KIO-300AS | – 5 mm x 25 m wire rope and hook K-11 – Pendant control K613 |
– Winch Weight : 19 kg – Gross Weight : 25 kg – Box Dimension : 500 x 250 x360 mm |
