| Item number | Rated load (kg) | Lifting speed m/min(m/sec) | Standard lift (m) | Supply pressure MPa(kgf/cm²) | Air consumption (m³/min) | |||
| No-load | Rated load | |||||||
| Lifting | Lowering | Lifting | Lowering | |||||
| KA1SN-025PB | 250 | 17 | 15 | 10 | 19 | 3 | 0.6 (6) | 1.4 |
| -0.283 | -0.25 | -0.167 | -0.137 | |||||
| KA1SN-050PB | 500 | 17 | 15 | 7.5 | 24 | 1.4 | ||
| -0.283 | -0.251 | -0.125 | -0.04 | |||||
| KA1SN-100PB | 1000 | 8.5 | 6.5 | 3.5 | 12 | 1.4 | ||
| -0.142 | -0.108 | -0.058 | -0.02 | |||||
| KA2SN-100PB | 1000 | 9 | 7 | 4.5 | 11 | 1.8 | ||
| -0.15 | -0.117 | -0.075 | -0.183 | |||||
| KA2SN-200PB | 2000 | 4.5 | 3.5 | 2.3 | 5.5 | 1.8 | ||
| -0.075 | -0.058 | -0.038 | -0.092 | |||||
| Item number | Rated load (kg) | Loading chain | Net weight (kg) | Connection diameter | |
| Wire size (mm) | Rope number | ||||
| KA1SN-025PB | 250 | 6.3 | 1 | 23 | Rc1/2″ |
| KA1SN-050PB | 500 | 23 | |||
| KA1SN-100PB | 1000 | 2 | 31 | ||
| KA2SN-100PB | 1000 | 7.1 | 1 | 40 | |
| KA2SN-200PB | 2000 | 2 | 45 | ||
