| Item no. | Rated load | Standard lift (m) | Hoisting speed m/sec (m/min) | Motor output (kW) | Rated time (min) | Load chain | Power cable length (m) | Push-button switch cord length S (m) | |||
| 50Hz | 60Hz | 50Hz | 60Hz | Diameter | No. of falls | ||||||
| ECC40030 | 300kg | 3 | 0.09 | 0.107 | 0.4 | 15 | 6.3 | 1 | 5 | 2.6 | |
| -5.4 | -6.4 | ||||||||||
| ECC40050 | 500kg | 0.053 | 0.063 | ||||||||
| -3.2 | -3.8 | ||||||||||
| ECCJ40100 | 1tw | 0.027 | 0.032 | 2 | |||||||
| -1.6 | (1.9)/td> | ||||||||||
| Item no. | Min. headroom G (mm) | Net weight* (kg) | Hook mass (kg) | External dimensions (mm) | ||||||
| A | B | D | E | F | P* | Q* | ||||
| ECC40030 | 485 | 36 | 0.7 | 245 | 245 | 137 | 149 | 20 | 660 | 195 |
| ECC40050 | 520 | 36 | ||||||||
| ECCJ40100 | 660 | 42 | 2.4 | 167 | 118 | 25 | 715 | 225 | ||
Notes:
