รอกโซ่ไฟฟ้า NICHI รุ่น MH5

High – Capacity Electric chain Hoist (3_phase 200V)

รอกโซ่ไฟฟ้า Electric Chain hoists NICHI High-Capacity Electric Chain Hoist MH5

High – Capacity Electric chain Hoist (3_phase 200V)



SPECIFICATIONS

Item no. Rated load (t) Standard lift (m) Hoisting speed Motor output (kW) Motor insulation class Rated time (min)
50Hz 60Hz 50Hz 60Hz
(m/sec) (m/min) (m/sec) (m/min)
MH5300 30 4 0.012 0.7 0.015 0.9 3.1×2 3.7×2 B 30
MH5400 40 0.008 0.5 0.01 0.6
MH5500 50 0.005 0.3 0.007 0.4
MH5600 60 Please consult us.



Item no. Rated load (t) Load chain Power cable length (m) Push-button switch cord length S (m) Min. headroom G (mm) Net weight* (kg)
Diameter No. of falls
MH5300 30 11.2 12 5 4.6 1,650 800
MH5400 40 16 5 2,000 1,300
MH5500 50 24 5.5 2,400 1,700
MH5600 60 Please consult us.

Notes:

  • Please contact us for specifications when using a high-capacity MH-5 in combination with an electric or a geared trolley.
  • The motor requires a winding that matches the specified voltage and frequency.
