| Item no. | Rated load (t) | Standard lift (m) | Hoisting speed | Motor output (kW) | Rated time (min) | Load chain | Power cable length (m) | ||||
| 50Hz | 60Hz | Diameter | No. of falls | ||||||||
| (m/sec) | (m/min) | (m/sec) | (m/min) | ||||||||
| MC5005 | 0.5 | 4 | 0.09 | 5.4 | 0.107 | 6.4 | 0.62 | 15 | 7.1 | 1 | 5 |
| MC5010 | 1 | 0.045 | 2.7 | 0.053 | 3.2 | ||||||
| Item no. | Rated load (t) | Push-button switch cord length S (m) | Test load (t) | Min. headroom G (mm) | Net weight* (kg) | Hook mass (kg) | External dimensions (mm) | ||||||
| A | B | D | E | F | *P | *Q | |||||||
| MC5005 | 0.5 | 3.6 | 0.625 | 550 | 58 | 0.7 | 305 | 285 | 152 | 106 | 20 | 795 | 220 |
| MC5010 | 1 | 1.25 | 560 | 0.9 | 25 | ||||||||
| Item no. | Rated load (t) | Standard lift (m) | Traversing | Traversing rail width b (mm) | |||||
| Speed | Motor output (kW) | Rated time (min) | |||||||
| 50Hz | 60Hz | ||||||||
| (m/sec) | (m/min) | (m/sec) | (m/min) | ||||||
| MCE5005 | 0.5 | 4 | 0.167 | 10 | 0.2 | 12 | 0.09 | 15 | 75,100,125 |
| MCE5010 | 1 | ||||||||
| Item no. | Rated load (t) | Min. curve radius (m) | Power cable length (m) | Min. headroom G (mm) | Net weight* (kg) | External dimensions (mm) | |||
| H | I | J | K | ||||||
| MCE5005 | 0.5 | 1 | 10 | 535 | 83 | b/2+222 | b/2+230 | 127 | 240 |
| MCE5010 | 1 | 545 | |||||||
| Item no. | Rated load (t) | External dimensions (mm) | |||||
| L | M | N | U | P* | Q* | ||
| MCE5005 | 0.5 | 32-t2 | b-49 | φ69 | 99+t2 | 675 | 220 |
| MCE5010 | 1 | ||||||
Notes:
