AUTOMOTIVE WINCH COME UP Electric Winch DV Series

กว้านสลิงติดรถยนต์ COME UP Electric Winch DV Series

Category กว้าน Tags COME UP, Hoist & Crane, กว้านสลิงติดรถยนต์, รอกและระบบลำเลียง

กว้านสลิงติดรถยนต์ COME UP Electric Winch DV Series

DV-6,DV-6s,DV-6s carry on,DV-9,DV-9i,DV-9s,DV-9si,DV-12,DV-12 light,DV-12s light,DV-15,DV-18

DV-6s

Heavy duty series wound motor delivers superior torque output and faster line speed.
Lightweight and compact design is easy for front of vehicle.
Submersible sealed contactor handles high amps and allows higher duty cycle.
12 strand construction synthetic rope, coated to improve abrasion resistance and to protect from the ingress of dirt and grit.

DV-6s carry on

Heavy duty series wound motor delivers superior torque output and faster line speed.
Lightweight and compact design is easy for front of vehicle.
2” hitch receiver and quick connector wiring kits for rear of vehicle.
Submersible sealed contactor handles high amps and allows higher duty cycle.

12 strand construction synthetic rope, coated to improve abrasion resistance and to protect from the ingress of dirt and grit.
The U.S Germany, U.K. France, etc patented automatic, full load cone brake structure outside the drum holds the full load without slippage.
Meet international standards of CE Machinery Directive 2006/42/EC, and CE Electromagnetic Compatibility Directive 2004/108/EC.

DV-6

Heavy duty series wound motor gives high torque and fast line speed.
3 stage planetary gearbox delivers the most reliable and durable performance of winch under the rugged conditions.
The U.S., Germany, U.K., France, etc patented automatic CBS (Cone Brake Structure) holds full load, maintenance with easy.
The greater the load on the wire rope, the greater amount of brake that is applied by the mechanism.
Rotating ring gear clutch is a pull and turn design for rapid wire rope payout.
2″ rear receiver and quick connector kits mounts directly to the vehicle frame without drilling.

SPECIFICATIONS กว้านสลิงติดรถยนต์ COME UP Electric Winch DV Series

Specifications	COME UP DV-6	COME UP DV-6s	COME UP DV-6s carry on
Part number	PN 854750 (12V) Std. drum / PN 854760 (12V) Long drum	PN 854752 (12V)	PN 854765 (12V)
Rated line pull	2,722 kg / 6,000 lb single line	2,722 kg / 6,000 lb single line	2,722 kg / 6,000 lb single line
Motor	2,390 w / 3.2 hp 12V series wound	2,390 w / 3.2 hp 12V series wound	2,390 w / 3.2 hp 12V series wound
Gear ratio	3-stage planetary 216:1	3-stage planetary 216:1	3-stage planetary 216:1
Clutch (freespooling)	Rotating ring gear	Rotating ring gear	Rotating ring gear
Brake (outside the drum)	Automatic, full load CBS (Cone Brake Structure)	Automatic, full load CBS (Cone Brake Structure)	Automatic, full load CBS (Cone Brake Structure)
Winch construction	Aluminum die cast housings with steel drum	Aluminum die cast housings with steel drum	Aluminum die cast housings with steel drum
Drum size:		63.5 x 125.5 mm (2.5” x 4.9”)	63.5 x 125.5 mm (2.5” x 4.9”)
DV-6 Std. Drum	63.5 x 125.5 mm (2.5” x 4.9”)
DV-6 Long drum	63.5 x 227 mm (2.5″ x 8.9″)
Control	Waterproof remote w/ 5 m (17′) cord	Waterproof remote w/ 5 m (17′) cord	Waterproof remote w/ 5 m (17′) cord
Rope type	Galvanized aircraft A7 x 19	Synthetic rope	Synthetic rope
Rope size:		8 mm x 24.4 m (5/16” x 80’)	8 mm x 24.4 m (5/16” x 80’)
DV-6 Std. drum	7.1 mm x 24.4 m (9/32” x 80’)
DV-6 Long drum	7.1 mm x 30.5 m (9/32″ x 100′)
Mounting bolts pattern:		152.4 mm x 114 mm (6” x 4.5”)	152.4 mm x 114 mm (6” x 4.5”)
DV-6 Std. drum	152.4 mm x 114 mm (6” x 4.5”)
DV-6 Long drum	254 mm x 114 mm (10″ x 4.5″)
Winch weight (including rope)		19 kg / 41.9 lb	22.8 kg / 50.3 lb
DV-6 Std. drum	22.8 kg / 50.3 lb
DV-6 Long drum	25.2 kg / 55.6 lb
Gross weight :		21.6 kg / 47.6 lb	27.4 kg / 60.4 lb
DV-6 Std. drum	28.4 kg / 62.6 lb
DV-6 Long drum	32.8 kg / 72.3 lb
Box dimension, (L x D x H)		505 x 210 x 340 mm (19.9″ x 8.3″ x 13.4″)	515 x 285 x 345 mm (20.3″ x 11.2″ x 13.6″)
DV-6 Std. drum	505 x 210 x 340 mm (19.9″ x 8.3″ x 13.4″)
DV-6 Long drum	672 x 210 x 390 mm (6.5″ x 8.3″ x 15.4″)

DV-9

All sealed high performance motor supplies superior torque output and faster line speed.
3 stage planetary gearbox delivers the most reliable and durable performance of winch under the rugged conditions.
The U.S., Germany, U.K., France, etc patented automatic CBS (Cone Brake Structure) holds firmly in full load and provides easy maintenance. Specific design of brake (CBS) outside the drum is ideally suited to heat-sensitive synthetic rope.

Heavy duty sealed contactor ensures sound waterproof protection.
Turn clutch by ergonomic T-handle for rapid rope payout. The equally positioned pin holes make it easily rotate by 40° increments for special in-bumper application.
Protective thermal sensor LED.

DV-9i

All sealed high performance motor supplies superior torque output and faster line speed.
3 stage planetary gearbox delivers the most reliable and durable performance of winch under the rugged conditions.
The U.S., Germany, U.K., France, etc patented automatic CBS (Cone Brake Structure) holds firmly in full load and provides easy

maintenance. Specific design of brake (CBS) outside the drum is ideally suited to heat-sensitive synthetic rope.
Heavy duty sealed contactor ensures sound waterproof protection.
Turn clutch by ergonomic T-handle for rapid rope payout. The equally positioned pin holes make it easily rotate by 40° increments for special in-bumper application.
Protective thermal sensor LED.

DV-9s

All sealed high performance motor supplies superior torque output and faster line speed.
3 stage planetary gearbox delivers the most reliable and durable performance of winch under the rugged conditions.
The U.S., Germany, U.K., France, etc patented automatic CBS (Cone Brake Structure) holds firmly in full load and provides easy maintenance. Specific design of brake (CBS) outside the drum is ideally suited to heat-sensitive synthetic rope.

Heavy duty sealed contactor ensures sound waterproof protection.
Turn clutch by ergonomic T-handle for rapid rope payout. The equally positioned pin holes make it easily rotate by 40° increments for special in-bumper application.
Protective thermal sensor LED.

DV-9si

All sealed high performance motor supplies superior torque output and faster line speed.
3 stage planetary gearbox delivers the most reliable and durable performance of winch under the rugged conditions.
The U.S., Germany, U.K., France, etc patented automatic CBS (Cone Brake Structure) holds firmly in full load and provides easy maintenance. Specific design of brake (CBS) outside the drum is ideally suited to heat-sensitive synthetic rope.

Heavy duty sealed contactor ensures sound waterproof protection.
Turn clutch by ergonomic T-handle for rapid rope payout. The equally positioned pin holes make it easily rotate by 40° increments for special in-bumper application.
Protective thermal sensor LED.

SPECIFICATIONS กว้านสลิงติดรถยนต์ COME UP Electric Winch DV Series

Specifications	COME UP DV-9	COME UP DV-9i	COME UP DV-9s	COME UP DV-9si
Part number	PN 856329 (12V) / PN 856355 (24V)	PN 856360 (12V) / PN 856388 (24V)	PN 859252 (12V) / PN 859262 (24V)	PN 859038 (12V) / PN 859055 (24V)
Rated line pull	4,082 kg / 9,000 lb single line	4,082 kg / 9,000 lb single line	4,082 kg / 9,000 lb single line	4,082 kg / 9,000 lb single line
Motor	3,430 w / 4.6 hp 12V series wound	3,430 w / 4.6 hp 12V series wound	3,430 w / 4.6 hp 12V series wound	3,430 w / 4.6 hp 12V series wound
Motor	1,940 w / 2.6 hp 24V series wound	1,940 w / 2.6 hp 24V series wound	1,940 w / 2.6 hp 24V series wound	1,940 w / 2.6 hp 24V series wound
Gear train	3-stage planetary 156:1	3-stage planetary 156:1	3-stage planetary 156:1	3-stage planetary 156:1
Clutch (freespooling)	Rotating ring gear	Rotating ring gear	Rotating ring gear	Rotating ring gear
Brake (outside the drum)	Automatic, full load CBS (Cone Brake Structure)	Automatic, full load CBS (Cone Brake Structure)	Automatic, full load CBS (Cone Brake Structure)	Automatic, full load CBS (Cone Brake Structure)
Winch construction	Aluminum die cast housings with steel drum	Aluminum die cast housings with steel drum	Aluminum die cast housings with steel drum	Aluminum die cast housings with steel drum
Drum size:	63.5 x 229 mm (2.5” x 9”)	63.5 x 229 mm (2.5” x 9”)	63.5 x 227 mm (2.5” x 8.9”)	63.5 x 227 mm (2.5” x 8.9”)
Control	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord
Rope type	Galvanized aircraft A7 x 19	Galvanized aircraft A7 x 19	Synthetic rope	Synthetic rope
Rope size:	8.3 mm x 30.5 m (21/64” x 100’)	8.3 mm x 30.5 m (21/64” x 100’)	10 mm x 30.5 m (3/8” x 100’)	10 mm x 30.5 m (3/8” x 100’)
Mounting bolts pattern:	254 x 114 mm (10” x 4.5”)	254 x 114 mm (10” x 4.5”)	254 x 114 mm (10” x 4.5”)	254 x 114 mm (10” x 4.5”)
Winch weight (including rope)	33 kg / 72.8 lb	37 kg / 81.6 lb	27 kg / 59.5 lb	31 kg / 68.3 lb
Gross weight :	43 kg / 94.8 lb	44 kg / 97 lb	33 kg / 72.8 lb	37 kg / 81.6 lb
Box dimension, (L x D x H)	650 x 195 x 415 mm (25.6″ x 7.7″ x 16.3″)	650 x 195 x 415 mm (25.6″ x 7.7″ x 16.3″)	650 x 195 x 415 mm (25.6″ x 7.7″ x 16.3″)	650 x 195 x 415 mm (25.6″ x 7.7″ x 16.3″)

DV-12

All sealed high performance motor supplies superior torque output and faster line speed.
3 stage planetary gearbox delivers the most reliable and durable performance of winch under the rugged conditions.
The U.S., Germany, U.K., France, etc patented automatic CBS (Cone Brake Structure) holds firmly in full load and provides easy maintenance. Specific design of brake (CBS) outside the drum is ideally suited to heat-sensitive synthetic rope.

Heavy duty sealed contactor ensures sound waterproof protection.
Turn clutch by ergonomic T-handle for rapid rope payout. The equally positioned pin holes make it easily rotate by 36° increments for special in-bumper application.
Protective thermal sensor LED.

DV-12 light

Reliable electric winch for working and playing in off-road environments
3,430w/12V or 1,940w/24V series wound motor.
9 equally positioned pin holes with a ergonomic T-handle make it possible to reposition in 40 degree Increments for customer and in bumper applications
Hardened steel, 3-stage planetary gear train for efficient and reliable operation.

Water-proof remote control with thermometric LED indicator alerts when the motor is over-heated.
U.S. Germany, U.K. France, etc patented mechanical CBS (Cone Brake Structure) holds the full load without slipping.
Submersible sealed contactor handles high amps and allows higher duty cycle.
Meet SAE J706, CE Machinery Directive 2006/42/EC and CE Electromagnetic Compatibility Directive 2004/108/EC.
(* Only foot forward mounting can meet SAE J706)

DV-12s light

Reliable electric winch for working and playing in off-road environments
3,430w/12V or 1,940w/24V series wound motor.
9 equally positioned pin holes with a ergonomic T-handle make it possible to reposition in 40 degree Increments for customer and in bumper applications
Hardened steel, 3-stage planetary gear train for efficient and reliable operation.

Water-proof remote control with thermometric LED indicator alerts when the motor is over-heated.
U.S. Germany, U.K. France, etc patented mechanical CBS (Cone Brake Structure) holds the full load without slipping.
Submersible sealed contactor handles high amps and allows higher duty cycle.
Meet SAE J706, CE Machinery Directive 2006/42/EC and CE Electromagnetic Compatibility Directive 2004/108/EC.
(* Only foot forward mounting can meet SAE J706)

SPECIFICATIONS กว้านสลิงติดรถยนต์ COME UP Electric Winch DV Series

Specifications	COME UP DV-12	COME UP DV-12 light	COME UPDV-12s light
Part number	PN 857130 (12V) / PN 857228 (24V)	PN 850012 (12V) / PN 850124 (24V)	PN 850125 (12V) / PN 851024 (24V)
Rated line pull	5,443 kg / 12,000 lb single line	5,443 kg / 12,000 lb single line	5,443 kg / 12,000 lb single line
Motor	4,180 w / 5.6 hp 12V series wound	3,430 w / 4.6 hp 12V series wound	3,430 w / 4.6 hp 12V series wound
Motor	2,690 w / 3.6 hp 24V series wound	1,940 w / 2.6 hp 24V series wound	1,940 w / 2.6 hp 24V series wound
Gear train	3-stage planetary 261:1	3-stage planetary 211:1	3-stage planetary 211:1
Clutch (freespooling)	Rotating ring gear	Rotating ring gear	Rotating ring gear
Brake (outside the drum)	Automatic, full load CBS (Cone Brake Structure)	Automatic, full load CBS (Cone Brake Structure)	Automatic, full load CBS (Cone Brake Structure)
Winch construction	Aluminum die cast housings with steel drum	Aluminum die cast housings with steel drum	Aluminum die cast housings with steel drum
Drum size:	89 x 206 mm (3.5” x 8.1”)	63.5 x 227 mm (2.5” x 8.9”)	63.5 x 227 mm (2.5” x 8.9”)
Control	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord
Rope type	Galvanized aircraft A7 x 19	Galvanized aircraft A7 x 19	Synthetic rope
Rope size:	9.5 mm x 38 m (3/8” x 125’)	9.5 mm x 25 m (3/8” x 82’)	11 mm x 25 m (7/16” x 82’)
Mounting bolts pattern	254 x 114 mm (10” x 4.5”)	254 x 114 mm (10” x 4.5”)	254 x 114 mm (10” x 4.5”)
Mounting bolts pattern	254 x 165 mm (10″ x 6.5″)	Foot forward mounting only	Foot forward mounting only
Winch weight (including rope)	55 kg / 121 lb	39 kg / 86 lb	30 kg / 66.1 lb
Gross weight	67 kg / 147.7 lb	49 kg / 108 lb	36 kg / 79.4 lb
Box dimension, (L x D x H)	694 x 265.2 x 418.4 mm ( 27.3″ x 10.4″ x 16.5″)	650 x 195 x 415 mm (25.6″ x 7.7″ x 16.3″)	650 x 195 x 415 mm (25.6″ x 7.7″ x 16.3″)

DV-15

All sealed high performance motor supplies superior torque output and faster line speed.
3 stage planetary gearbox delivers the most reliable and durable performance of winch under the rugged conditions.
The U.S., Germany, U.K., France, etc patented automatic CBS (Cone Brake Structure) holds firmly in full load and provides easy maintenance. Specific design of brake (CBS) outside the drum is ideally suited to heat-sensitive synthetic rope.

Heavy duty sealed contactor ensures sound waterproof protection.
Turn clutch by ergonomic T-handle for rapid rope payout. The equally positioned pin holes make it easily rotate by 36° increments for special in-bumper application.
Protective thermal sensor LED.

DV-18

Features compact size, light-weight, extreme low profile and spec. leading 18,000 lb pulling make it the optimal winch to fit in the limited space on most of the current vehicles.
10 equally positioned pin holes with a stainless steel ergonomic T-handle make it possible to reposition in 36 degree Increments.
Hardened steel, 3-stage planetary gear train for efficient and reliable operation

Water-proof remote control with thermometric LED indicator alerts when the motor is over-heated.
U.S. Germany, U.K. France, etc patented mechanical cone brake holds the full load without slipping.
Meet international standards such as SAE J706, CE Machinery Directive 2006/42/EC, and REMSA.

SPECIFICATIONS กว้านสลิงติดรถยนต์ COME UP Electric Winch DV Series

Specifications	COME UP DV-15	COME UP DV-18
Part number	PN 857326 (12V) / PN 857433 (24V)	PN 851823 (12V) / PN 851838 (24V)
Rated line pull	6,804 kg / 15,000 lb single line	8,181 kg / 18,000 lb single line
Motor	4,180 w / 5.6 hp 12V series wound	5,220 w / 7.0 hp 12V series wound w/thermal protcetion switch
Motor	2,690 w / 3.6 hp 24V series wound	4,474 w / 6.0 hp 24V series wound w/thermal protcetion switch
Gear train	3-stage planetary 315:1	3-stage planetary 315:1
Clutch (freespooling)	Rotating ring gear	Rotating ring gear
Brake (outside the drum)	Automatic, full load CBS (Cone Brake Structure)	Automatic, full load CBS (Cone Brake Structure)
Winch construction	Aluminum die cast housings with steel drum	Aluminum die cast housings with steel drum
Drum size:	89 x 206 mm (3.5” x 8.1”)	89 x 192 mm (3.5″ x 7.6″)
Control	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord	Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord
Rope type	6 × 29 – IWRC	6 × 29 – IWRC
Rope size:	11.1 mm x 27 m (7/16” x 89’)	12.7 mm x 25 m (1/2” x 82’)
Mounting bolts pattern	254 x 114 mm (10” x 4.5”)	254 x 114 mm (10” x 4.5”)
	254 x 165 mm (10″ x 6.5″)	254 x 165 mm (10″ x 6.5″)
		Foot forward mounting only
Winch weight (including rope)	57 kg / 125.4 l	59 kg / 130 lb
Gross weight	69 kg / 152 lb	71 kg / 156.5 lb
Box dimension, (L x D x H)	694 x 265.2 x 418.4 mm ( 27.3″ x 10.4″ x 16.5″)	694.2 x 265.2 x 418.4 mm ( 27.3″ x 10.4″ x 16.5″)
